FURITEK KOMODO UNITY 10 PRO SENSORED Competition 2000KV

The World's First 2-in-1 Outrunner Brushless Motor with Integrated FOC ESC and Sensored Technology for 1/10 RC Crawlers

The FURITEK KOMODO UNITY 10 PRO SENSORED Competition is the next generation of the UNITY platform.

Built around Furitek's integrated 2-in-1 architecture, it combines a high-performance FOC ESC and an outrunner brushless motor into one compact unit. Now equipped with an integrated magnetic sensor system, it delivers smoother startup, more precise throttle control, and significantly improved crawling performance.

Designed for serious crawler enthusiasts and competition drivers, the UNITY 10 PRO SENSORED provides exceptional torque, cleaner installation, lower weight, and advanced tuning features developed specifically for technical crawling.

Built for Competition

Whether you're climbing vertical ledges, navigating competition gates, or crawling across technical rock sections, the UNITY 10 PRO SENSORED delivers predictable power and outstanding low-speed control.

The integrated ESC design eliminates unnecessary wiring, reduces overall weight, improves chassis layout, and makes installation cleaner than traditional ESC and motor setups.

Adjustable Startup Mode

The PRO SENSORED version introduces a fully adjustable startup system. Using the Furicar App, drivers can select the startup behavior that best matches their driving style.

SINE Startup - Factory Default

By default, the motor starts using Furitek's SINE startup algorithm before automatically transitioning into full sensored FOC operation.

• Ultra-smooth startup
• Maximum crawling precision
• Better control on technical obstacles
• Reduced drivetrain shock

Direct Sensored Startup

For drivers who prefer a more direct throttle feel, SINE Startup can be disabled directly in the Furicar App.

Thanks to the integrated magnetic sensor system, the motor still starts extremely smoothly without relying on the SINE startup sequence.

• Faster throttle response
• More direct power delivery
• Excellent low-speed control
• Ideal for competition driving

FURITEK SMART DRAG BRAKE™

The UNITY 10 PRO SENSORED introduces FURITEK SMART DRAG BRAKE™, a braking system designed specifically for sensored FOC crawling.

Instead of applying a fixed braking force like conventional drag brake systems, SMART DRAG BRAKE™ continuously uses real-time rotor position feedback from the integrated magnetic sensor to regulate braking torque with much higher accuracy.

The result is smoother downhill control, stronger hill holding, and a much more predictable driving experience on technical terrain.

• More accurate drag brake modulation
• Stronger and more consistent hill holding
• Smoother transition between throttle and braking
• Improved control on steep descents
• Reduced drivetrain shock
• More precise control on technical obstacles

True Sensored FOC Control

The integrated magnetic sensor continuously monitors rotor position and provides the ESC with accurate motor position feedback in real time.

• Ultra-smooth startup
• Precise throttle control
• Consistent torque delivery
• Reduced cogging
• Improved low-speed control

Wireless Tuning with Furicar App

Configure the system directly from the Furicar App.

• Startup Mode
• SMART DRAG BRAKE™

• Punch
• Throttle Curve
• Motor Parameters
• Firmware Updates

No external programmer or PC is required.

Compact 2-in-1 Design

With the ESC integrated directly into the motor, the UNITY 10 PRO SENSORED provides a much cleaner and more efficient chassis layout.

• Less wiring
• Cleaner installation
• More chassis space
• Lower overall system weight
• Better layout for competition builds

High Performance

• Motor KV: 2000KV
• Maximum Power: Up to 280W
• Continuous Current: 50A
• Burst Current: 100A
• Battery Support: 2S to 4S LiPo

Integrated 5A BEC

• 5.5V
• 7.4V
• 8.4V

Designed to support high-performance crawler servos and electronics.

Lightweight Competition Design

The integrated design reduces unnecessary hardware and wiring while keeping the power system compact and competition-ready.

Specifications

Package Includes

• 1x FURITEK KOMODO UNITY 10 PRO SENSORED Competition 2000KV, 2-in-1 Motor + ESC with XT60 connector
• 1x User Manual

Built for Precision

The FURITEK KOMODO UNITY 10 PRO SENSORED combines Furitek's integrated 2-in-1 architecture with sensored FOC control, adjustable startup modes, and FURITEK SMART DRAG BRAKE™.

Every part of the system is designed around one goal: precise, predictable control for serious 1/10 RC crawling.
