FURITEK TORPEDO Brushless Power System For TRX-4M

SKU: FUR-2342
$149.99
  • Brand: Furitek
  • Availability: In Stock

  FURITEK TORPEDO BRUSHLESS POWER SYSTEM for TRX-4M FURITEK team in the past 2 years have been designed and produced several brushless ESCs for mini crawlers with the famous LIZARD line of ESCs.  Being the first FOC-technology ESCs ever being designed and produced for the mini crawlers, the LIZARD ESCs...

Import tax can be charged at receiving. Buyers are responsible to pay import tax if incurred

UPS cannot deliver to a PO Box



FURITEK TORPEDO BRUSHLESS POWER SYSTEM for TRX-4M



FURITEK team in the past 2 years have been designed and produced several brushless ESCs for mini crawlers with the famous LIZARD line of ESCs.  Being the first FOC-technology ESCs ever being designed and produced for the mini crawlers, the LIZARD ESCs have changed the games for the mini crawlers.  They are super small in size, butterly smooth and amazingly powerful.  Together with the famous brushless outrunner KOMODO motors, they offer incredible performance for the mini crawlers.

However the team is not stopping; after over 6 months of testing and designing, FURITEK team releases another next evolution of the FURITEK ESCs, the high-end, upper performance line of brushless ESC for mini crawlers.  Introducing the new FURITEK PYTHON brushless ESCs that inherited the awesome features above of the LIZARD ESCs but now with new enclosing case for dust proof and waterproof.  We no longer have to worry about the brownout of the big servos or heavy weight of some modified trucks with huge 5A built-in BEC that can be run at multiple voltage from 5.5V to 7.4V for Python and up to 8.4V for the Python PRO.  We also no longer need to wire a separate bigger BEC for the ESC. The FURITEK team also releases a completely new patent-pending brushless inrunner motor, the CEDAR.  The CEDAR brushless inrunner motor is super smooth, waterproof and dustproof and easy to be installed in any mini chassis.

FURITEK TORPEDO brushless system for TRX-4M is the powerful and top of the line combo of the CEDAR motor and PYTHON PRO esc.  It offers nothing but the best on the market for TRX-4M.  The CEDAR comes with the 11T steel pinion to fit perfectly on TRX-4M.

PYTHON PRO ESC Features:

- FOC (Field-Orientated control) technology

- Live tunning on Furicar app

- Super slow and ridiculously smooth throttle control

- New firmware algorithm to consistently smooth up the start up to FOC stage

- Work with Brushed/Brushless motors (config via app, default is brushless)

- BIG BEC for power-hungry servos

- Mini size and light weight

- Super easy programming via App on both Android and iOS

- Real-time telemetry up to 10Hz

- Bluetooth module built-in so no longer a separate wires and bluetooth module controlled by Furicar App

- Waterproof and dustproof with an enclosing CNC aluminum case

- Circuit protection

- FREE lifetime firmware updates

PYTHON PRO Specifications:

- Supports 2-4S lipo batteries

- BEC: 5.5V/7.4V/8.4V 5A

- Constant current: 40A

- Burst current: 70A

- Built-in power switch

- Dimensions: 1.57x 0.78x 0.6 (inch), 40x20x15 (mm)

- Weight: 5.7g (0.2oz)

CEDAR motor Features:

- Special designed 12-Pole Inrunner brushless motor for most efficiency

- Waterproof design

- Dustproof design

- Small, compact, easy to be installed in tight spaces

- Stylish with aluminum case, anodized with red and black

- Super quiet, high torque, powerful and super slow speed yet tons of wheel speeds when needed

- Steel pinion included for TRX-4M crawlers

- High purity and higher temperature copper windings -lower copper losses, very good heat dissipating-maximizes efficiency.

- Super thin (0.2mm) stator laminations---lower eddy losses---maximizes efficiency. High RPM ABEC5 bearings.

- Precision balanced rotor, smoothness for best reliability, and maximum RPM. CNC machined 6061 T6 billet aluminum heatsink can.

- Precision engineered for maximum energy conversion

- All hardware included

CEDAR motor Specifications:

- Motor type: Inrunner

- KV: 3456KV­­

- No-load current @10V: 07A

- Power: 120W

- Battery: 2-3S Lipo

- Resistance: 0.17Ohm

- Slot/Pole: 12-Pole

- Motor size: 18x25mm diameter (0.7 x 1inch)

- Weight: 20g (0.7oz)

NOTE: We highly suggest a low reduction gearing for better crawling performance specially in low RPM



Extra requirements:

- A new 3-4 channel radio system is required




Customer Reviews

Based on 7 reviews
86%
(6)
0%
(0)
14%
(1)
0%
(0)
0%
(0)
P
Preston Cox
Awesome

So much power from such a little package

C
Cuiken
Not bad but a few issues

I fitted the Furitek Torpedo combo to my TRX4M K10 truck using the stock TRX4M gears and have had a mixed experience with it:

The good: FOC is superb. Hardware installation was nice and easy. Everything fits as it should.

Slow speed control is just amazing.

Top speed is pretty high great fun on the trails since the TRX4m is a fairly capable chassis even at speed.

The bad: With stock gearing, I get quite a lot of cogging when trying to crawl over technical obstacles.

For some reason reverse is way (way) faster than forward. The Throttle page in the app tells me I have forward and reverse both hitting 100% but I need to set reverse at 50% maximum to get it to be just a little slower than forward at 100%.

The app has been pretty flaky. When I try to run a calibration, it doesn't work at all. Reverse is unchanged but forward becomes digital. Either 0% or 100%. I have to factory reset the ESC to fix this every time I try to calibrate.

Feels like it could be a nice product when a few more of these bugs are worked out.

A
Allan Favino
Torpedo for a Ripper

Being my first small scale truck, I figured I'd go all out. It had to be a Furitek Torpedo. I'm still working on tuning the settings in the ESC. Bluetooth connectivity is fantastic. It's extremely smooth and quiet while operating at low speeds. Very satisfied.

W
Wayne Smith
Absolutely Superb

A great service and product from Furitek. The build quality and compactness make this ideal for todays crawling demands.
If you’re in two minds about buying, do it you won’t regret it

C
Christopher Bailey
Furitek torpedo system next level control

This system is awesome the slow crawl control is next level. Take your rig to the next level. I can't recommend it enough

Tags: TRX4M COMBO
